Waveform Generators

Rigol DG5502 Pro

Rs. 693490.00

The Rigol DG5000 Pro Series is a dual-channel function and arbitrary waveform generator offering high-performance with up to 500 MHz bandwidth, 2.5 GSa/s sample rate, and 16-bit resolution. With a 64 Mpts memory depth (expandable to 128 Mpts) and a 10.1" touch display, it provides versatile signal generation capabilities for various applications, including function, arbitrary waveform, noise, pulse, harmonic, modulation, and counter generation. It features USB, LAN, and Web Control interfaces, making it highly compatible for automated testing and measurement systems..

  • Detail
  • Special Features
  • Specification

✨ Why It Helps (Cause → Effect)

  • 2.5 GSa/s sample rate → tiny time steps → accurate high-frequency output.

  • 16-bit resolution → fine voltage steps → smoother, clearer waves.

  • 64 Mpts memory (up to 128 Mpts) → long, complex sequences → fewer loops, fewer gaps.

  • Dual channels → synchronized or independent → richer tests in less time.

🎛 Core Signal Tools (Action → Outcome)

  • Function, ARB, pulse, noise, harmonic → one box, many cases.

  • Analog + digital modulation → real-world signal stress → better validation.

  • Harmonic generation → expose nonlinearity → tune filters faster.

📡 Where It Fits (Task → Result)

  • RF testing → generate clean carriers → measure true behavior.

  • Communications → model modulated links → verify timing and depth.

  • Modulation analysis → sweep, burst, and step → find weak spots early.

đŸ–Ĩ Use & Control (Step → Payoff)

  • 10.1″ touchscreen + quick keys → find settings fast → fewer missteps.

  • Web Control in a browser → remote tweaks → easy automation.

  • USB/LAN connectivity → simple scripts → smooth rack integration.

✨ Dual-Channel Functionality
Two independent channels → same full features on both → sync signals cleanly or run them solo.

đŸ”Ŧ High-Resolution Waveforms
16-bit vertical steps → finer levels → waveforms look smooth and stay precise.

📡 Wide Frequency Range
1 µHz → 500 MHz → ultra-slow to very fast → one box covers many jobs.

⚡ High Sample Rate & Deep Memory
2.5 GSa/s + 64 Mpts per channel (expandable to 128 Mpts) → sharp details + long sequences → complex shapes stay accurate.

🧩 Advanced Modulation
Analog + digital mods → build real-world signals → ideal for comms and RF tests.

🧰 Multiple Output Modes
Function gen + ARB + noise + pulse + harmonic + counter → many tools → fewer boxes on the bench.

đŸ–Ĩī¸ Intuitive User Interface
10.1″ touch display → clear menus, quick keys, easy inputs → find settings fast.

🌐 Web Control
Open a browser → control the instrument → remote tweaks without extra software.

🔌 USB & LAN Connectivity
USB + LAN on board → simple hookup, easy scripts → smooth automation.

đŸ–ŧī¸ HDMI Display Out
Plug an external screen → get a bigger view → teach, demo, or review with the team.

  • Model: DG5252 Pro, DG5352 Pro, DG5502 Pro

  • Max Frequency: 250 MHz, 350 MHz, 500 MHz

  • Max Sample Rate: 2.5 GSa/s

  • Vertical Resolution: 16 bits

  • Waveform Memory Depth: 64 Mpts (standard), 128 Mpts (optional)

  • Amplitude Range: 1 mVpp to 10 Vpp (high impedance)

  • Resolution: 1 µHz

  • Channels: 2

  • Interfaces: USB, LAN, HDMI

  • Display: 10.1" TFT-Color-LCD (800 x 480 pixels)

  • Power Supply: AC 100V~240V (50/60 Hz)

  • Warranty: 3 years

  • Frequency Counter: Up to 1 GHz

Model Overview

Model Max Frequency Max Sample Rate Memory Depth Amplitude Range
DG5252 Pro 250 MHz 2.5 GSa/s 64 Mpts (128 Mpts) 1 mVpp to 10 Vpp
DG5352 Pro 350 MHz 2.5 GSa/s 64 Mpts (128 Mpts) 1 mVpp to 10 Vpp
DG5502 Pro 500 MHz 2.5 GSa/s 64 Mpts (128 Mpts) 1 mVpp to 10 Vpp



Price

  • ₹1,20,000.00

  • ₹1,41,600.00 (Including 18% GST)

The Rigol DG5000 Pro Series function and arbitrary waveform generators are ideal for users requiring high-frequency, high-precision waveform generation. With their dual-channel capability, advanced modulation options, and easy-to-use interface, they serve a wide range of applications, including RF testing, communications, signal analysis, and system development.
