SEALEVEL | PCI Express

COMM+16.PCIe

Now includes NABL Calibration Certificate.

The COMM+16.PCIe is a 16-port RS-232 PCI Express serial adapter supporting data rates up to 460.8K bps. It is designed for high-performance, data-intensive applications, providing reliable communication with a wide range of peripherals..

  • Detail
  • Special Features
  • Specification

The COMM+16.PCIe: 16-Port DB25 PCI Express RS-232 Serial Adapter is built for applications that require high-density serial communication. It provides 16 RS-232 serial ports, each capable of data rates up to 460.8K bps. The 16C854 UARTs offer 128-byte Tx/Rx FIFOs, ensuring reliable data transmission in demanding environments. The adapter supports all modem control signals for compatibility with a wide variety of serial peripherals. For easy installation, it ships with two 36-inch cables terminating in DB25M connectors; DB9M cables can be selected if needed. The PCI Express X1 compliant card ensures fast and efficient communication, ideal for industrial automation, data logging, and other applications that require a large number of serial connections.

  • 16 RS-232 serial ports with modem control signals

  • Data rates up to 460.8K bps

  • Uses 16C854 UARTs with 128-byte Tx/Rx FIFOs for enhanced reliability

  • PCI Express X1 compliant

  • Ships with two 36-inch cables, terminating in 16 DB25M connectors

  • Option to select DB9M connector cables

  • Operating temperature range: 0°C to 70°C

  • Ideal for high-density serial communication in industrial automation systems

  • Product Name: COMM+16.PCIe: 16-Port DB25 PCI Express RS-232 Serial Adapter

  • Host Interface: PCI Express

  • Number of Ports: 16

  • Max Data Rate: 460.8K bps

  • Max Data Distance: 50 feet

  • Operating Temperature: 0°C to 70°C (32°F to 158°F)

  • Communications Chip: 16C854

  • Dimensions: 5.5" (L) x 4.4" (W)

  • Serial Connector(s): DB25M, DB9M (with appropriate cables)

  • Cable Length: 36 inches (included)
