ITECH | DC Power Supply

ITech IT6123B

Rs. 72900.00

The ITECH IT6123B is a precision programmable DC power supply capable of delivering up to 60V and 30A with a maximum output power of 600W. Engineered for high-speed, low-noise applications, it offers excellent performance in terms of voltage/current accuracy, transient response, and programmability. Whether in R&D labs or automated test systems, the IT6123B provides the stability, control, and safety needed for reliable operation..

  • Detail
  • Special Features
  • Specification

The IT6123B is part of ITECH’s high-speed power supply series, designed to support demanding applications in electronics testing, power module validation, and industrial quality assurance. Its rapid command response time and built-in waveform simulation tools make it ideal for real-world testing scenarios. The unit allows detailed customization of voltage and current profiles, with the added ability to adjust slew rates for accurate transient behavior simulation. Multiple communication interfaces and robust protection circuits ensure seamless integration and safe operation in both benchtop and system environments.

  1. 60V / 30A / 600W high-output performance

  2. 1mV / 0.1mA high resolution for precise control

  3. Fast transient response and low ripple output

  4. LIST and STEP functions for dynamic testing sequences

  5. Voltage and current slew rate programming

  6. Built-in protection: OVP, OCP, OTP, and remote sense

  7. Full interface suite: USB, RS232, GPIB, and LAN

  8. Compact, rack-mountable, and space-efficient design

Parameter Value
Model IT6123B
Output Voltage 0 – 60 V
Output Current 0 – 30 A
Output Power 600 W
Voltage Resolution 1 mV
Current Resolution 0.1 mA
Voltage Accuracy ≤ 0.03% + 10 mV
Current Accuracy ≤ 0.05% + 10 mA
Ripple & Noise (Vpp) ≤ 10 mV
Transient Response ≤ 50 µs
Slew Rate Control Supported
LIST/STEP Modes Supported
Display VFD
Communication Ports USB, RS232, GPIB, LAN (standard)
Protection OVP, OCP, OTP, Remote Sense
Dimensions (W×H×D) 215 × 88.2 × 354 mm
Weight Approx. 6.5 kg
