ITECH | DC Power Supply

IT6502D(G)

Rs. 119610.00

The ITECH IT6502D(G) is a compact and efficient programmable DC power supply that delivers up to 60V and 15A with a maximum power output of 360W. It is engineered for high precision, fast response, and low noise, making it ideal for research labs, industrial production, and educational institutions. With adjustable voltage rise/fall times, built-in waveform simulation, and multiple communication interfaces, this power supply offers unmatched flexibility and control in a space-saving design..

  • Detail
  • Special Features
  • Specification

The IT6502D(G) from ITECH is designed to deliver precise, stable, and programmable DC output for a wide range of applications. The unit's fast transient response and low ripple make it particularly suitable for sensitive electronics testing. Engineers can use the LIST/STEP modes to simulate real-world power scenarios, while the adjustable rise/fall time enhances realism in voltage transitions. It comes equipped with essential protections and standard communication interfaces, ensuring safety and seamless integration into automated testing environments. Its compact form factor allows for efficient space utilization in bench setups or rack systems.

  • High resolution of 1mV/0.1mA for accurate output control

  • Fast transient response with rapid recovery under load changes

  • Adjustable voltage rise and fall time for simulation accuracy

  • LIST/STEP function for pre-programmed voltage/current sequences

  • Ultra-low ripple and noise for clean and stable power delivery

  • Comprehensive protection: OVP (Over Voltage), OCP (Over Current), OTP (Over Temperature)

  • Standard USB and RS232 interfaces; optional LAN and GPIB available

  • Compact, lightweight chassis with stackable design

Parameter Value
Model IT6502D(G)
Output Voltage 0 – 60 V
Output Current 0 – 15 A
Output Power 360 W
Voltage Resolution 1 mV
Current Resolution 0.1 mA
Voltage Accuracy ≤ 0.03% + 10 mV
Current Accuracy ≤ 0.05% + 10 mA
Ripple & Noise (Vpp) ≤ 10 mV
Rise/Fall Time 2.5 ms typical
Communication Ports USB, RS232 (standard); GPIB, LAN (optional)
Display VFD or LCD (model dependent)
Protection Features OVP, OCP, OTP
Dimensions (W×H×D) 215 × 88.2 × 354 mm
Weight Approx. 6.5 kg
